Home USB Cable
USB 3.0 Print

Product Description:

  • Tinned, Annealed, Stranded Copper Conductor
  • Insulation Material: Foam Skin Polyethylene (Signal)
  • Insulation Material: Polyvinyl Chloride (Power)
  • Jacket Material: Polyvinyl Chloride
  • Rate Temperature: 80 °C
  • Rated Voltage: 30V
  • Standard: UL 1581 (UNDERWRITERS LABORATORIES)
    CONTRUCTION:

usb 3.0


Marking:  USB 3.0  28AWG/3P  28AWG/2C     PAN-INTERNATIONAL  2725  E87647-M  UL  AWM  80°C  30V      ROHS


AWG Size Conductor Insulation Diameter (mm) Braid Shieled Overall Diameter
STP Signal UTP Signal Power
28AWG 7 / 0.127 0.93 ± 0.05 0.80 ± 0.05 0.80 ± 0.05 85% 5.50 ± 0.15


USB 2.0






Physical Construction Description:

One 28AWG pair and two 28AWG conductors are cabled

together with an aluminum/PET tape and an overall braid

shield with 85% coverage. A PVC jacket is then applied with

an overall OD of 0.17"±0.02". Standard jacket color is light

grey, but black is also available. The conductors and pairs are

color coded for ease of identification. USB Cables are

available in various constructions.
